Kawasaki K3VL Series High-Performance Variable Axial Piston Pumps

Product Overview: The Kawasaki K3VL series is a range of swash-plate type variable displacement axial piston pumps designed for open-circuit industrial and mobile applications. Renowned for their “High Power Density” and “Superior Self-Priming Capability,” this series covers a comprehensive displacement range from the compact 28cc (K3VL28) and mainstream 45cc (K3VL45) to the heavy-duty 112cc (K3VL112). Featured models like the K3VL28/C-1NRSM-L1 and K3VL112/B-1NRMM-L0 deliver precise and stable flow output at a rated pressure of 320 Bar. Their rugged construction and versatile control options make them the ideal choice for CNC machines, die-casting equipment, and industrial Hydraulic Power Units (HPU).

Key Technical Advantages:

• Superior Power-to-Weight Ratio: Engineered with high-strength materials and a compact frame to deliver massive pressure output within a minimal installation footprint.

• Excellent Self-Priming Performance: Optimized valve plate design and suction flow paths allow the K3VL series to maintain high suction efficiency at elevated speeds, reducing the need for charge pumps.

• Versatile Control Modalities: Offers Load Sensing, Torque Limiting, and Electronic Control options, accurately matching power output to load demand for significant energy savings.

• Low Noise Operation: Optimized swashplate dynamics effectively suppress hydraulic ripples and structural noise, enhancing the industrial workspace environment.

• Modular Through-Drive Capability: Supports tandem mounting of additional piston or gear pumps, facilitating the construction of complex multi-circuit hydraulic systems.

Detailed Models & Parameters:

• Core Series: Kawasaki K3VL Series (Swash Plate Type).

• Model Keywords: K3VL28, K3VL45, K3VL60, K3VL80, K3VL112, K3VL140, K3VL200.

• Full Config Codes: K3VL28/C-1NRSM-L1, K3VL45/B-1NRSM-L0, K3VL112/B-1NRMM-L0/1-H4.

• Displacements: 28 cm³/rev to 200 cm³/rev.

• Pressure Ratings: Rated at 320 Bar (4640 PSI) continuous; Peak capability up to 350 Bar (5075 PSI).

• Rotation: R (Clockwise/CW); L (Counter-clockwise/CCW).

• Target Applications: Injection molding machines, high-pressure presses, mobile drive systems, and marine deck machinery.
