Industrial Standard Hydraulic Cylinder Series (CDM1 / SBD / CHH)

Product Overview:

As a leading hydraulic cylinder manufacturer, we provide heavy-duty actuators meeting the 2026 international industrial standards. This range features the ISO 6020-1 compliant CDM1 series, alongside the precision-optimized SBD and CHH series for high-frequency applications. Covering bore sizes from $32\text{mm}$ to $80\text{mm}$ and strokes up to $900\text{mm}$, these cylinders ensure superior performance at a nominal pressure of $16 \text{ MPa}$ ($160 \text{ bar}$).

Core Model Specifications:

• CDM1MS2/32/22/900A10/B11HHUMW (R407999226):

  • Specs: $32\text{mm}$ Bore, $22\text{mm}$ Rod, $900\text{mm}$ Stroke.

  • Mount: MS2 (Side Lugs/Foot Mount). Fully compliant with ISO 6020-1 for global interchangeability.

• 80SBDHMIRN11M250.00M1400:

  • Specs: $80\text{mm}$ Bore, $250.00\text{mm}$ Stroke.

  • Features: HMIRN advanced sealing system, engineered for heavy-duty thrust and precise positioning.

• 50CHHHMIRN21MC600M1100:

  • Specs: $50\text{mm}$ Bore, $600\text{mm}$ Stroke.

  • Features: High-speed response series with 21MC reinforced interfaces for automation lines.

Key Technical Advantages:

• Global ISO 6020-1 Interchangeability: The CDM1 series strictly follows international standards, ensuring $100\%$ physical replacement for Rexroth and other major brands, simplifying procurement.

• 160bar Consistent Power: Rated at $16 \text{ MPa}$. High-precision honed barrels guarantee excellent linearity and mechanical efficiency even during $900\text{mm}$ long-stroke operations.

• HMIRN Precision Sealing: Equipped with the latest low-friction composite seals for extreme wear resistance and zero-leakage performance, eliminating “stick-slip” motion at low speeds.

• Heavy-Duty MS2 Mounting: The foot-mounted base is optimized via FEA (Finite Element Analysis) to disperse axial stress during long-stroke cycles, preventing mounting face deformation.

• Induction-Hardened Rods: High surface hardness with superior corrosion resistance, designed for the diverse shop floor environments and high-dust conditions of 2026.

Detailed Technical Specifications:

• Nominal Pressure: $16 \text{ MPa}$ ($160 \text{ bar}$).

• Bore Sizes: $32 \text{ mm}, 50 \text{ mm}, 80 \text{ mm}$.

• Stroke Range: From $250 \text{ mm}$ up to $900 \text{ mm}$.

• Seal Material: High-grade Nitrile (NBR) or Viton (FKM).
