Cartridge Solenoid Valve EP08W EP13A | EP08W2A02N | EP13A2A02N | 2-Way 2-Position Poppet Valve | Hydraulic Integrated Circuit
| Model Number | EP08W2A02N05, EP08W2A06N04, EP08W2A01M05, EP13A2A02N05 |
|---|
Product Description
EP Series Screw-in Hydraulic Cartridge Solenoid Valves
Product Overview: The EP series is a range of industrial-grade screw-in cartridge solenoid valves designed specifically for Hydraulic Integrated Circuits (HICs). This series covers the standard 08 (7/8-14UNF) and 13 (1-1/16-12UN) cavity sizes. Utilizing a Poppet-type internal structure, the EP series stands out for its extremely low internal leakage (near zero-leakage) and excellent contaminant tolerance. Whether used for actuator load-holding, system unloading, or as a pilot stage, the EP series provides highly reliable switching within a compact footprint.
Featured models include: EP13A2A02N05, EP08W2A02N05, EP08W2A06N04, and the manual version EP08W2A01M05.
Key Technical Advantages:
Zero/Low Leakage Poppet Design: Unlike spool valves, the poppet-seat seal provides an almost airtight closure, making it the ideal choice for pressure-holding circuits and load-support systems.
Compact Screw-in Mounting: The cartridge design drastically reduces the volume of the hydraulic power unit, simplifies plumbing, and allows for easy maintenance and rapid replacement.
High-Response Solenoid Actuation: Compatible with various coil specifications (DC 12V/24V or AC 110V/220V), offering fast switching speeds and high repeatability.
Versatile Override Options: Available with N (No manual override) and M (Manual override) options, ensuring manual intervention is possible during power loss or system commissioning.
Detailed Specifications & Parameters:
Featured Model Matrix:
EP08W2A02N05: Size 08, 2-Way 2-Pos, Normally Closed, no manual override, standard seals.
EP13A2A02N05: Size 13 High-flow version, 2-Way 2-Pos, Normally Closed.
EP08W2A06N04: Size 08 version with specific flow/pressure drop configuration.
EP08W2A01M05: Size 08, includes type M manual override for enhanced field emergency capability.
Core Technical Specs:
Cavity Sizes: 08-Size (VC08-2) / 13-Size (VC13-2).
Rated Pressure: Rated up to 21 MPa (210 bar) to 25 MPa.
Max Flow Capacity: Approx 20-30 L/min for 08 series; up to 60-80 L/min for 13 series.
Fluid Compatibility: Mineral-based hydraulic oils.
