Hydac Type WSM06020Z Solenoid Poppet Valve | 10V 12V 24V 36V DC | WSM06020Z-01-C-N | Leak-proof

WSM06020Z Series Normally Closed Solenoid Poppet Valves

Product Overview: The WSM06020Z series is a high-efficiency, cartridge-style direct-acting solenoid poppet valve. As a Normally Closed (N.C.) valve, it utilizes a precision poppet architecture to achieve absolute zero leakage in the de-energized state, effectively eliminating actuator drift. Its compact design allows for direct installation into the standard UNF 3/4-16 (Size 06) cavity, making it an ideal choice for mobile equipment, outrigger locking, and pressure-holding circuits in lifting platforms.

Featured models include: WSM06020Z-01-C-N-10DG, 12DG, 24DG, and 36DG for specialized power systems.

Key Technical Advantages:

• Zero Internal Leakage: The poppet-style hard seal ensures complete hydraulic isolation in the closed position, far outperforming spool valves for long-term load-holding tasks.

• Rapid Direct-Acting Response: The armature directly drives the poppet for a simple, reliable structure with millisecond-level switching (< 50ms).

• Comprehensive Voltage Solutions: Available in a full range of coil options from industrial 24V to specialized 10V/36V systems, catering to diverse global platforms.

• All-Weather Solenoid: Featuring a wet-pin construction with 360° rotatable coils, providing excellent vibration resistance and heat dissipation.

Detailed Specifications & Parameters:

• Featured Model Matrix:

  • WSM06020Z-01-C-N-10DG: 10V DC supply, for specialized mobile control units.

  • WSM06020Z-01-C-N-12DG: 12V DC supply, standard for most vehicle battery systems.

  • WSM06020Z-01-C-N-24DG: 24V DC supply, industrial and heavy machinery standard.

  • WSM06020Z-01-C-N-36DG: 36V DC supply, ideal for high-voltage battery-operated equipment.

• Core Technical Specs:

  • Cavity: Size 06 (UNF 3/4-16).

  • Max Operating Pressure: 250 bar (3625 PSI).

  • Rated Flow Rate: Up to 20 L/min.

  • Electrical Connection: DG (DIN 43650 Standard Connectors).

  • Seals: NBR (N-Seals), compatible with mineral-based hydraulic oils.

WSM06020Z-01-C-N-12DG
WSM06020Z-01-C-N-24DG
WSM06020Z-01-C-N-36DG WSM06020Z-01-C-N-48DG
WSM06020Z-01-C-N-110DG
WSM06020Z-01-C-N-24AG
WSM06020Z-01-C-N-115
WSM06020Z-01-C-N-230AG
WSM06020Z-01M-C-N-24DG
WSM06020Z-01M-C-N-48DG
WSM06020Z-01M-C-N-110DG
WSM06020Z-01M-C-N-24AG
WSM06020Z-01M-C-N-115
WSM06020Z-01M-C-N-230AG
WSM06020ZR-01M-C-N-24DG
WSM06020ZR-01-C-N-24DG
WSM06020Y-01M-C-N-24DG
WSM06020Y-01-C-N-24DG
WSM06020YR-01M-C-N-24DG
WSM06020YR-01-C-N-24DG
WSM06020W-01M-C-N-24DG
WSM06020W-01-C-N-24DG
WSM06020YR-01-C-N-24DG
WSM06020YR-01-C-N-230AG
WSM08130C-01-C-N-24DG
WSM08130C-01-C-N-230AG
WSM10120Z-01-C-N-24DG
WSM10120Z-01-C-N-230AG
WSM10120ZR-01-C-N-24DG
WSM10120ZR-01-C-N-230AG
WSM10120Y-01-C-N-24DG
WSM10120Y-01-C-N-230AG
WSM10120YR-01-C-N-24DG
