D-Series Industrial High-Pressure Filter Elements (0240D/0260D/0280D)

Product Overview:

This series of high-pressure filter elements is specifically engineered for Hydac pressure line filter housings, serving as the ultimate defense for servo valves, proportional valves, and downstream precision components. In 2026, across high-precision injection molding, steel mill rolling mills, and power plant control systems, the 0240D005BH4HC series utilizes superior micron-level technology to keep fluid integrity within ISO 4406 standards.

Featured Models Covered:

• 0240D005BH4HC/-V (Viton Seal, High-Collapse)

• 0240D005BH4HC (Standard High-Collapse)

• 0240D005ON (High-Performance Betamicron series)

• Series Compatibility: 0240D, 0260D, 0280D series.

Key Technical Advantages:

• BH4HC Extreme Collapse Resistance: Designed for high-pressure systems without bypass valves, featuring a reinforced hexagonal core that sustains collapse pressures up to $210 \text{ bar}$, preventing structural failure under high differential pressure.

• ON (Betamicron®) Media: Employs next-generation gradient composite glass fiber providing an absolute efficiency of $\beta_5(c) \ge 1000$, with $30\%$ higher dirt-holding capacity.

• V (Viton/FKM) Seals: Models with the -V suffix are tailored for high temperatures (up to $120^\circ\text{C}$) and specialized fluids (e.g., phosphate esters), ensuring zero-leakage in harsh environments.

• $100\%$ Physical Interchangeability: Manufactured strictly to OEM dimensional tolerances, ensuring a perfect fit with 0240D/0280D filter housings.

• Depth Filtration Structure: Scientifically optimized pleat density maximizes the filtration area, significantly reducing the initial pressure drop.

Detailed Specifications:

• Filtration Rating: $5\mu\text{m}$ (Absolute).

• Collapse Rating: $210 \text{ bar}$ (BH4HC Grade).

• Seal Material: Standard NBR; -V models feature Viton (FKM).

• Applicable Series: 0240D, 0260D, 0280D.

• Compatible Mediums: Hydraulic oils, lubricants, water-glycols, and flame-resistant fluids.
