Hägglunds CA & CB Series Heavy-Duty Radial Piston Hydraulic Motors

Product Overview: The Hägglunds CA and CB Series represent the pinnacle of “Peak Torque” in the global industrial drive sector. As high-efficiency LSHT (Low Speed High Torque) radial piston motors, they are engineered to provide direct, powerful drive solutions in the most extreme industrial environments. This selection spans from the compact CA50, CA70, and CA100 to the heavy-duty CA210, CB280, CB400, and CB560, featuring the core configuration: CA210 210 SA0N00 02 33. Renowned for their gearless direct-drive capability, these motors are widely used in mining crushers, feeder winches, belt conveyors, plastic extruders, and marine deck machinery.

Key Technical Advantages:

• Elite Starting Torque: The unique radial piston arrangement ensures nearly 100% of full-load torque is available at zero speed, ideal for high-inertia start-up conditions.

• Shock Resistance & Durability: Engineered to withstand violent load fluctuations and external impacts, maintaining stable operation for tens of thousands of hours even under frequent reversals.

• Compact Direct Drive: Connects directly to the main shaft via hollow shafts or splines, eliminating the need for gearboxes and couplings, which significantly boosts mechanical efficiency and saves space.

• Dual/Multi-Displacement Control: Supports dynamic displacement shifting during operation, providing flexible adjustment between speed and torque for various work cycles.

• Low-Speed Smoothness: Delivers pulse-free, smooth output even at ultra-low speeds (<1 RPM), ensuring precise process control.

• Target Applications: Industrial shredders, bucket wheel excavators, rubber mixers, marine net haulers, and sugar mill press drives.

Detailed Models & Parameters:

• Core Series: Hägglunds CA Series & CB Series (Radial Piston Technology).

• Model Keywords: CA50, CA70, CA100, CA140, CA210, CB280, CB400, CB560.

• Technical Specs Decoding (CA210 210 SA0N00 02 33):

  • CA210: 210cc/rev displacement frame size.

  • SA0N00: Refers to standard spline shafting, specialized distribution seals, and housing configurations.

  • 02 33: Indicates specific cam-lobe curve codes and factory technical version standards.

• Pressure Specs: Rated continuous pressure up to 350 Bar (5000 PSI).
