H10B Series Hydraulic Solenoid Valve | 34BY | 34EH | 24EO | 24BH | NG10 Directional Valve
| Model Number | 24EO-H10B-T, 24BO-H10B-T, 24EH-H10B-T, 24BH-H10B-T, 34BY-H10B-T, 34EH-H10B-T, 34BH-H10B-T |
|---|
Product Description
H10B Series Industrial Hydraulic Solenoid Directional Valves
Product Overview: The H10B series serves as the primary directional control valve for complex motion sequences in hydraulic systems. Featuring a subplate mounting design that complies with international installation standards, this series is renowned for its powerful shifting force and high-pressure tolerance. It ensures precise logic actuation even under high-frequency switching and harsh operating conditions. From the 3-position 4-way 34BY series to the 2-position 4-way 24EO series, high-performance wet-pin solenoids are used for exceptional heat dissipation and low-noise operation.
Featured models: 34BY-H10B-T, 34EH-H10B-T, 34BH-H10B-T, 24EO-H10B-T, 24BO-H10B-T, 24EH-H10B-T, and 24BH-H10B-T.
Key Technical Advantages:
Diverse Functional Options: Covers a wide range of spool functions, including all-ports-open, closed-center, and pressure unloading centers to meet various circuit requirements.
Wet-Pin Solenoid Drive: The armature is fully immersed in oil, resulting in low friction and eliminating the need for pushrod seals, effectively preventing external oil leakage.
Robust -T Connection Design: The -T suffix denotes optimized connection/drain characteristics, ensuring agile and reliable spool movement even under high-pressure return line conditions.
High-Reliability Valve Body: Constructed from high-strength precision casting with internal galleries optimized for fluid dynamics to minimize pressure drops and heat generation.
Detailed Specifications & Parameters:
Featured Model Matrix:
34BY / 34EH / 34BH: 3-position 4-way series with various center configurations.
24EO / 24BO / 24EH / 24BH: 2-position 4-way series, including single and dual solenoid setups.
Core Technical Specs:
Nominal Size: 10mm (NG10 / CETOP 5).
Max Operating Pressure: Up to 31.5 MPa (315 bar).
Max Flow Rate: Up to 120 – 160 L/min.
Voltage Ratings: Available in AC 220V, AC 110V, DC 24V, and DC 12V.
Enclosure Rating: IP65.
