GPY Series High Pressure Gear Pump | GPY-4R, GPY-8R, GPY-11.5R | Power Unit Pump
| Model Number | GPY-3R 4R 5.8R 7R 8R 9R 10R 11.5R |
|---|
Product Description
GPY Series High-Performance Micro Power Unit Gear Oil Pumps
Product Overview: The GPY Series is a high-pressure power core specifically engineered for compact hydraulic systems. As a premier external gear pump, this series is the industry standard for AC/DC micro-hydraulic power units due to its exceptional power density and pressure-balancing capabilities. This featured range includes core models: the top-selling GPY-4R, GPY-F8R, and the high-displacement GPY-11.5R. Featuring reinforced aluminum alloy bodies and specialized surface treatments, these pumps deliver outstanding operational stability even under frequent start-stop cycles and continuous high pressure (Rated 21 MPa).
Key Technical Advantages:
Ultra-Compact Footprint: Optimized for the limited internal space of power packs, with flange and shaft specs designed for direct integration with mainstream motors.
High Pressure Resilience: Rated for a continuous working pressure of 21 MPa (210 Bar) with peak pressures reaching 25 MPa, ideal for heavy-duty lifting and clamping applications.
Axial Gap Compensation: Equipped with floating bushing technology that adjusts clearances based on real-time load. This maintains volumetric efficiency above 93%, effectively minimizing system heat and extending seal life.
High-Speed Capability: Optimized gear set design supports high-speed operation up to 3500-4000 RPM, allowing for smaller pump sizes while maintaining rapid system flow response.
Target Applications: Truck tail lifts, electric forklift steering circuits, hydraulic lifting platforms, micro-sweepers, and various mini-hydraulic power units.
Detailed Models & Parameters:
Core Series: GPY High Pressure Series.
Model Keywords: GPY-3R, GPY-4R, GPY-5.8R, GPY-7R, GPY-8R, GPY-9R, GPY-10R, GPY-11.5R, GPY-F8R.
Displacements (ml/rev): Covering precise specs from 3ml/rev (GPY-3R) up to 11.5ml/rev (GPY-11.5R).
Pressure Ratings: Rated at 21 MPa (210 Bar/3000 PSI); Peak pressure up to 25 MPa (3625 PSI).
Rotation: R (Standard Clockwise); L (Counter-Clockwise) configurations available.
