GPA Series Internal Gear Pump | GPA1, GPA2, GPA3-63-E-20-R | Silent Servo Pump
| Model Number | GPA3-63-E-20-R6.3, GPA1 GPA2 GPA3 |
|---|
Product Description
GPA Series High-Performance Silent Internal Gear Pumps
Product Overview: The GPA Series is engineered as the “Silent Heart” for precision hydraulic systems. As a premium internal gear pump, the GPA series is the preferred choice for servo-driven injection molding machines, CNC machine tools, and automated production lines due to its exceptional low-noise performance and extreme pressure stability. This featured range includes the GPA1, GPA2, and GPA3 frames, highlighting the core model GPA3-63-E-20-R6.3 and a full displacement spectrum from 1cc to 63cc. Its “straight conjugate” internal meshing technology ensures superior response speed and energy efficiency when paired with variable-speed servo drives.
Key Technical Advantages:
Ultimate Silence & Low Pulsation: Utilizing the internal meshing principle, operational noise is 15-20 dB lower than conventional pumps. Minimal pressure ripples drastically enhance the repeatability of precision molded or machined parts.
Dual Pressure Compensation: Equipped with automated axial and radial pressure compensation mechanisms, maintaining volumetric efficiency above 95% throughout its service life, effectively reducing oil overheating.
Optimized for Servo Drives: Exceptional low-speed, high-pressure characteristics allow for stable pressure output at minimal RPMs, synchronizing perfectly with servo motor dynamics for maximum energy savings.
High Pressure & Longevity: Built with high-tensile materials and hardened gears, with rated pressures up to 16-20 MPa and high peak load capacity.
Target Applications: Servo injection molding machines, CNC bending machines, automated hydraulic power units, footwear machinery, and precision presses.
Detailed Models & Parameters:
Core Series: GPA1, GPA2, GPA3 Internal Gear Pump Series.
Model Keywords: GPA3-63-E-20-R6.3, GPA1, GPA2, GPA3-1, GPA3-2, GPA3-4, GPA3-6, GPA3-10, GPA3-16, GPA3-25, GPA3-40, GPA3-63.
Displacements (cm³/rev): Covering precise specs: 1, 2, 4, 6, 10, 16, 25, 40, and 63.
Pressure Ratings: Class E (16 MPa) and related high-pressure configuration options.
Technical Codes: R6.3 (Defining Clockwise Rotation and specific shaft/flange protocols).
