Eaton Char-Lynn H Series & 2000 Series LSHT Hydraulic Orbit Motors

Product Overview: This category highlights two iconic power units from the Eaton Char-Lynn family: the classic light-to-medium duty benchmark H Series (101-2577-009, 101-1027-009) and the medium-heavy duty performance standard 2000 Series (158-4088-001). Specifically engineered for Low Speed High Torque (LSHT) operations, these motors deliver stable and robust power in the most demanding industrial and mobile environments. Whether you require the compact flexibility of the spool-valve H Series or the high-pressure efficiency of the disc-valve 2000 Series, these are the premier choices for food processing machinery, harvester reel drives, conveyor systems, commercial mowers, and small industrial drives.

Key Technical Advantages:

• Spool Valve vs. Disc Valve: The H Series offers exceptional value and compactness, while the 2000 Series provides superior volumetric efficiency and extended service life through disc-valve technology.

• Geroler® Roller Geometry: Internal roller supports minimize startup friction, ensuring smooth and pulse-free operation even at ultra-low speeds.

• Elite Load Resilience: Model 158-4088-001 is designed with enhanced radial load capacity, accommodating various direct-drive configurations.

• High-Pressure Shaft Seals: Equipped with premium high-pressure seals, allowing for zero-leakage operation in most standard applications without the need for an external case drain.

Detailed Specifications & Parameters:

• Core Series: Eaton Char-Lynn H Series & 2000 Series.

• Featured Model Matrix: 158-4088-001, 101-2577-009, 101-1027-009.

• Core Performance Specs:

  • Displacement Range: 38 cc/rev to 490 cc/rev (2.3 – 30.0 cu in/rev).

  • Rated Pressure: Continuous up to 125 Bar – 200 Bar (1800 – 2900 PSI) (model dependent).

  • Torque Capability: Continuous torque ranging from 60 Nm to 845 Nm.

  • Mounting Standards: Standard 2-Bolt SAE A flange with 1-inch or 1-1/4 inch Keyed shaft options.
