Eaton Char-Lynn High Torque LSHT Hydraulic Motors

Product Overview: The Eaton Char-Lynn series of orbital motors stands as the global performance benchmark for High Torque Low Speed (LSHT) drive technology. This category highlights the essential models for industrial, agricultural, and construction applications: 104-3497-006, 104-1533-006, 104-3498-006 (2000 Series Disc Valve), compact 101-1700-009, 101-2473-009 (H Series), and the professional 129-0668-002. Engineered with advanced Geroler® sealing and valve technology, these motors deliver high mechanical efficiency at startup and ensure an extended service life under severe heavy-duty conditions. They are the premier choice for conveyors, harvesters, winches, tillers, and various industrial drive systems.

Key Technical Advantages:

• Geroler® & Gerotor Geometry: Minimizes internal friction and enhances efficiency, ensuring smooth, stable operation at low speeds with massive power delivery.

• Disc Valve Technology: The 104- series utilizes a disc valve design to reduce internal leakage, providing superior performance under high-pressure continuous operation.

• Superior Radial Load Capacity: Reinforced output shaft bearings allow the motor to handle significant side loads directly, simplifying machine architecture by eliminating the need for extra bearing supports.

• Global Standard Compatibility: Standard SAE mounting flanges and shaft types ensure a perfect drop-in replacement for original Eaton Char-Lynn equipment, minimizing maintenance downtime.

• Technical Spec Decoding:

  • 104- Series: The renowned 2000 Series, a mid-to-heavy duty disc valve motor.

  • 101- Series: Classic H Series spool valve motor, optimized for compactness and efficiency.

  • 129- Series: Specialized sequence optimized for heavy-duty professional applications.

Detailed Models & Specifications:

• Core Series: Eaton Char-Lynn High Torque LSHT Motor.

• Featured Model Matrix:

  • 104-3497-006 / 104-1533-006 / 104-3498-006: Core 2000 Series displacements with high pressure resilience.

  • 101-1700-009 / 101-2473-009: Compact H Series specifications for space-constrained drives.

  • 129-0668-002: Reinforced professional variant.

• Core Performance Specs:

  • Rated Pressure: Continuous up to 200 Bar (3000 PSI).

  • Torque Output: Capable of delivering 200 Nm to 900 Nm (depending on displacement).

  • Mounting Standards: Fully compliant with SAE 2-Bolt / 4-Bolt interfaces.
