Eaton Char-Lynn LSHT Motor | 109-1246-006, 112-1359-006, 106-1111-006 | Hydraulic Orbit Motor

Eaton Char-Lynn High Torque LSHT Hydraulic Orbit Motors

Product Overview: Eaton Char-Lynn orbit motors are the industry standard for hydraulic drives, recognized worldwide for their exceptional reliability, high power density, and massive torque output. This selection features core part numbers across the 2000, 4000, 6000, and 10000 series, including 112-1359-006, 109-1246-006, 109-1236-006, and 106-1111-006. Utilizing advanced Disc Valve technology and Geroler® stator sets, these motors maintain superior volumetric efficiency even in the harshest operating conditions.

Key Technical Advantages:

• Superior LSHT Performance: Low-Speed High-Torque design allows for direct drive of heavy loads without the need for gear reducers, simplifying the drivetrain.

• Advanced Disc Valve Engineering: Compared to spool valve motors, the disc valve design significantly reduces internal leakage, enhancing motor life and efficiency at high pressures.

• High-Pressure Shaft Seals: Equipped with premium seals that allow for high back pressures, reducing the necessity for external drain lines in many applications.

• Geroler® Stator Technology: Precision rollers reduce friction, providing smoother low-speed operation and higher starting torque.

• Target Applications: Harvester drives, rotary drill rigs, forestry equipment, injection molding machines, and heavy-duty winch systems.

Detailed Models & Parameters:

• Core Series: Eaton Char-Lynn 2000, 4000, 6000 Series.

• Model Keywords: 104, 105, 106, 109, 112-1359-006, 109-1246-006, 109-1236-006, 106-1111-006.

• Technical Specs Decoding:

  • 112-1359-006: Size 10000 series, providing ultimate torque output for ultra-heavy-duty tasks.

  • 109-1246-006 / 109-1236-006: Classic 4000 series, offering a perfect balance of flow and pressure performance for agricultural machinery.

  • 106-1111-006: 6000 series, engineered for high side-load capacity and high power requirements.

• Pressure Specs: Continuous pressure up to 200 Bar – 310 Bar (3000 – 4500 PSI) depending on the series.

• Displacement Range: Offering a broad spectrum from 80 cm³/rev up to 985 cm³/rev.
