Eaton Char-Lynn 6000 Series Motor | 112-1131-006 112-1098-006 112-1099-006 112-1132-005
| Model Number | 112-1131-006, 112-1098-006, 112-1099-006, 112-1132-005 |
|---|
Product Description
Eaton Char-Lynn 6000 Series (6K) Heavy-Duty LSHT Orbit Motors
Product Overview: The Eaton Char-Lynn 6000 Series (112- Series) represents the peak of heavy-duty orbital hydraulic motor performance. This category features the industry-leading models: 112-1131-006, 112-1098-006, 112-1099-006, and 112-1132-005. Utilizing precision Disc Valve technology, the 6000 Series is engineered to maintain peak efficiency under continuous high-pressure conditions. Its patented Geroler® roller set minimizes startup friction, ensuring powerful and smooth operation even at ultra-low speeds. These motors are the premier choice for heavy-duty propel systems, forestry equipment, large industrial agitators, oil drilling machinery, and heavy winches.
Key Technical Advantages:
Elite Disc Valve Precision: The independent valve plate balances clearances automatically under pressure, maintaining superior volumetric efficiency throughout the motor’s life.
Extreme Load Resilience: Robust housing with oversized tapered roller bearings allows the output shaft to handle massive radial and axial loads directly.
Geroler® Smoothness: Roller supports reduce friction, providing exceptional Low Speed High Torque (LSHT) performance suited for harsh duty cycles.
Technical Decoding:
112-1131-006 / 112-1132-005: Features oversized shafts and mounting interfaces for maximum connection stability in heavy-duty setups.
112-1098-006 / 112-1099-006: Standard displacement configurations with high global interchangeability.
Detailed Specifications & Parameters:
Core Series: Eaton Char-Lynn 6000 Series (6K Series).
Featured Model Matrix: 112-1131-006, 112-1098-006, 112-1099-006, 112-1132-005.
Core Performance Specs:
Displacement Range: 195 cc/rev to 985 cc/rev (11.9 – 60.0 cu in/rev).
Rated Pressure: Continuous up to 210 Bar (3000 PSI); Intermittent peaks up to 310 Bar (4500 PSI).
Torque Capability: Continuous torque up to 2200 Nm, with peak torque exceeding 3400 Nm.
Flow Capacity: Supports high flow inputs up to 150 L/min (40 GPM).
Mounting Standards: Standard 4-Bolt Square flange with 1-1/2″ or 2″ Keyed or Splined shaft options.
