Eaton Char-Lynn 6000 Series Motor | 112-1012-006 112-1062-006 112-1092-006

Eaton Char-Lynn 6000 Series (6 Series) Heavy-Duty Orbit Motors

Product Overview: The Eaton Char-Lynn 6000 Series (commonly known as the 6 Series) is the globally recognized benchmark for heavy-duty orbital hydraulic driving technology. This category highlights the cornerstone models: 112-1012-006, 112-1062-006, and 112-1092-006. Engineered with premium Disc Valve technology, the 6000 Series is designed to maintain peak volumetric efficiency under continuous high-pressure and high-flow conditions. Its patented Geroler® roller set design significantly reduces mechanical friction, ensuring unparalleled power stability in Low Speed High Torque (LSHT) applications. These motors are the premier choice for construction machinery propel drives, heavy-duty wheel drives, marine winches, forestry equipment, and large-scale agricultural systems.

Key Technical Advantages:

• Disc Valve Precision: The independent valve plate automatically balances clearances under pressure, providing superior efficiency and significantly longer service life compared to spool valve motors.

• Elite Radial Load Resilience: Equipped with oversized tapered roller bearings, the housing handles massive radial and axial loads directly—ideal for direct-drive wheel or gear-driven setups.

• Geroler® Roller Geometry: Internal roller supports minimize startup friction and ensure smooth, pulse-free operation even at minimal speeds under extreme loads.

• Technical Decoding:

  • 112-1012-006 / 112-1092-006: Features standard 4-Bolt mounting and heavy-duty shaft options (Splined or Keyed).

  • 112-1062-006: Optimized for specialized high-torque scenarios with enhanced sealing and drive link durability.

Detailed Specifications & Parameters:

• Core Series: Eaton Char-Lynn 6000 Series (6 Series).

• Featured Model Matrix: 112-1012-006, 112-1062-006, 112-1092-006.

• Core Performance Specs:

  • Displacement Range: 195 cc/rev to 985 cc/rev (12.0 – 60.0 cu in/rev).

  • Rated Pressure: Continuous up to 210 Bar (3000 PSI); Intermittent peaks up to 310 Bar (4500 PSI).

  • Torque Capability: Continuous torque exceeds 1500 Nm, with peak torque surpassing 2200 Nm.

  • Flow Rate: Handles continuous flow inputs up to 150 L/min (40 GPM).

  • Mounting Standards: Standard 4-Bolt SAE CC or Wheel Mount flanges with Splined or 1-1/2″ Keyed shaft options.
