Eaton Char-Lynn 6000 Series (114-) Bearingless Heavy-Duty Orbit Motors

Product Overview: The Eaton Char-Lynn 6000 Series 114- sequence represents the pinnacle of compact integration in orbital motor technology. This category highlights essential models: 114-1080-006, 114-1047, 114-1079-006, and 114-1032-006. Featuring a specialized Bearingless design, these motors are engineered without an internal output shaft or bearing set, allowing for direct mounting into gear reducers, planetary gearboxes, or wheel hub drives. Powered by the core Disc Valve technology, the 114- series provides massive torque while significantly reducing the overall machine envelope, making it the perfect choice for mobile cranes, heavy construction vehicle propels, agricultural harvester heads, and marine auxiliary systems.

Key Technical Advantages:

• Ultra-Compact Bearingless Design: This “Short Motor” configuration utilizes the external machinery’s bearing support, drastically reducing weight and saving critical installation space.

• Disc Valve Precision: An independent valve plate automatically adjusts for clearances under pressure, maintaining superior volumetric efficiency even during high-pressure pulses and frequent reversing.

• Geroler® Roller Geometry: Incorporates roller contacts in the star-and-ring set to minimize friction losses, ensuring ultra-smooth performance in Low Speed High Torque (LSHT) conditions.

• High Power Density: Despite its compact frame, its pressure and torque ratings fully match the 6000 series heavy-duty standard for rigorous operations.

• Technical Spec Decoding:

  • 114- Series: Identifies the 6000 Series variants designed for bearingless integration.

  • 1080 / 1047 / 1032: Relates to displacement specifics (310cc to 985cc) and internal spline configurations for gearbox mating.

Detailed Models & Specifications:

• Core Series: Eaton Char-Lynn 6000 Series (Bearingless Type).

• Featured Model Matrix:

  • 114-1080-006 / 114-1079-006: Core integration frames widely used for planetary gearbox interfaces.

  • 114-1047 / 114-1032-006: Customized displacement variants optimized for specific heavy-load duty cycles.

• Core Performance Specs:

  • Rated Pressure: Continuous up to 240 Bar (3500 PSI); Intermittent peaks up to 310 Bar.

  • Torque Capability: Continuous torque output ranging from 1000 Nm to over 2500 Nm.

  • Max Speed: Supports rotation up to 400-600 RPM (displacement dependent).
