Eaton Char-Lynn 2K 4K 6K Hydraulic Motor | Heavy Duty Motor for Water Well Drilling Rig

2K, 4K, 6K Series Hydraulic Motors for Water Well Drilling Rigs

Product Overview: In the demanding environment of water well drilling, power stability defines project success. We provide Eaton Char-Lynn 2K (2000), 4K (4000), and 6K (6000) Series orbital hydraulic motors specifically engineered for drilling rigs. These motors, renowned for their superior LSHT (Low Speed High Torque) performance, effortlessly handle critical tasks such as drill pipe rotation, hoisting, and propulsion drives.

Incorporating patented Geroler technology, these motors minimize internal friction and guarantee consistent torque output even under the high-pressure conditions of deep-well operations. They are the premier power core for truck-mounted rigs, crawler drills, top-drive systems, and various rock drilling equipment.

Key Technical Advantages:

• Elite Penetration Power: The 6K and 4K series deliver massive startup torque, ensuring the drill bit initiates smoothly in hard rock formations without lag.

• Heavy-Duty Bearing Architecture: Engineered to sustain intense axial and radial shock loads from the drill string, significantly extending maintenance intervals.

• Advanced High-Pressure Sealing: Features premium shaft seals that manage high system back-pressure efficiently, minimizing the risk of leaks in the field.

• 100% OEM Interchangeability: Fully compatible with Eaton standards, covering 104-105 (2K), 109-110 (4K), and 112-113 (6K) series.

Detailed Specifications & Parameters:

• Core Series: Char-Lynn 2,000, 4,000, 6,000 Series (2K, 4K, 6K).

• Featured Model Matrix: 2000 Series, 4000 Series, 6000 Series, LSHT Orbital Motor.

• Core Performance Specs:

  • Displacement Range: 80 cc/rev (2K) up to 985 cc/rev (6K).

  • Rated Pressure: Continuous up to 210-250 Bar (3050-3600 PSI); Intermittent peaks up to 310 Bar.

  • Torque Capability: Continuous torque up to 2,400 Nm (6K) and 1,100 Nm (4K).

  • Mounting Standards: Standard SAE A, SAE B, SAE C, and Wheel Mount flanges.

  • Shaft Options: 1-1/4″ and 1-1/2″ Keyed or Splined shafts for high-strength power transmission.
