Eaton Char-Lynn 2000 Series Motor | 109-1119-006, 109-1118-006, 109-1116-006

Eaton Char-Lynn 2000 Series High-Torque Geroler Hydraulic Motors

Product Overview: The Eaton Char-Lynn 2000 Series (2-Series) is the industry standard for medium-duty hydraulic drives. As a definitive LSHT (Low Speed High Torque) Geroler motor, it incorporates advanced Geroler® technology to deliver massive continuous torque within a compact footprint. This selection highlights core 109-series configurations: 109-1119-006, 109-1118-006, 109-1116-006, and 109-1173-006. Renowned for its superior volumetric efficiency and extended service life, the 2000 Series is widely utilized in agricultural machinery, conveyor systems, turf equipment, snow blowers, and industrial drives.

Key Technical Advantages:

• Geroler® Roller Stator Technology: The unique roller design minimizes friction, boosts starting efficiency, and ensures exceptionally smooth operation at ultra-low speeds.

• High-Pressure Shaft Seals: Features premium seals that handle high back pressures, often eliminating the need for a case drain in various configurations.

• Superior Power Density: The compact architecture provides significantly higher torque output compared to competitors, ideal for space-constrained installations.

• Robust Triple Bearing Design: Engineered with high-performance bearings to handle moderate radial and axial loads, ensuring reliability in harsh outdoor environments.

• Target Applications: Harvester conveyors, material handling, plastic injection auxiliary drives, vehicle-mounted winches, and auger drives.

Detailed Models & Parameters:

• Core Series: Eaton Char-Lynn 2000 Series (2-Series).

• Model Keywords: 109-1119-006, 109-1118-006, 109-1116-006, 109-1173-006, 109-1119, 109-1118.

• Technical Specs Decoding:

  • 109-1116-006: Approx. 160 cm³/rev displacement.

  • 109-1118-006: Approx. 200 cm³/rev displacement.

  • 109-1119-006: Approx. 250 cm³/rev displacement, balancing speed and torque.

  • 109-1173-006: Specialized configuration (specific shafts or mounting flanges).

• Pressure Specs: Continuous pressure up to 200 Bar (3000 PSI), with higher intermittent peak ratings.
