Eaton Char-Lynn 2000 Series Motor | 104-1066-006 104-1067-006 104-1068-006 | Disc Valve Orbit Motor

Eaton Char-Lynn 2000 Series (104-) High Torque Disc Valve Orbit Motors

Product Overview: The Eaton Char-Lynn 2000 Series (104- sequence) is the global benchmark for industrial-grade LSHT (Low Speed High Torque) orbital drive systems. This category features the high-stability models: 104-1066-006, 104-1067-006, and 104-1068-006. Engineered with advanced Disc Valve technology and the signature Geroler® roller set, these motors deliver peak torques exceeding 900 Nm. Their robust 4-bolt mounting design makes them the premier choice for harvester drives, injection molding screws, construction propel motors, heavy conveyor systems, and marine deck machinery.

Key Technical Advantages:

• Disc Valve Precision: The independent valve plate design automatically compensates for wear, ensuring superior volumetric efficiency and providing precise torque delivery even under extreme pressure cycles.

• Geroler® Roller Technology: Incorporates roller contacts in the star-and-ring set to minimize startup friction, providing pulse-free operation in LSHT tasks and ensuring exceptional smoothness at low speeds.

• Elite Bearing Load Resilience: Equipped with heavy-duty tapered roller bearings, the motor shaft handles immense radial and axial loads directly—simplifying machine design by removing the need for external bearing supports.

• Seamless Drop-in Compatibility: The 104- sequence strictly adheres to industrial mounting standards, offering a high-reliability replacement for original Eaton, Danfoss, or Parker heavy-duty motors.

• Technical Decoding:

  • 104-106x Series: Identifies 2000 Series frame sizes with specific flange and shaft configuration sequences.

  • Suffix -006: Denotes the standard industrial configuration for extended service life.

Detailed Models & Specifications:

• Core Series: Eaton Char-Lynn 2000 Series (Disc Valve Motor).

• Featured Model Matrix: 104-1066-006, 104-1067-006, 104-1068-006.

• Core Performance Specs:

  • Rated Pressure: Continuous up to 200 Bar (3000 PSI); intermittent peaks up to 310 Bar.

  • Torque Capability: Continuous torque output ranging from 450 Nm to over 900 Nm (displacement dependent).

  • Mounting Standard: Standard 4-Bolt flange with Keyed or Splined shaft options.
