Eaton Char-Lynn 2000 Series High Torque Orbital Hydraulic Motors

Product Overview: The Eaton Char-Lynn 2000 Series (104- sequence) stands as the performance benchmark for industrial Low Speed High Torque (LSHT) hydraulic drives. This category highlights essential models: 104-1023-006, 104-1024-006, 104-1025-006, 104-1026-006, and 104-1027-006. Engineered with advanced Disc Valve technology and the signature Geroler® roller set, these motors are designed to withstand high-pressure spikes and extreme loading. They are the premier choice for agricultural propel drives, heavy-duty winches, plastic injection molding, municipal sweepers, and conveyor drive systems.

Key Technical Advantages:

• Disc Valve Precision: The independent valve plate design automatically compensates for wear, significantly reducing internal leakage compared to spool valve designs, ensuring smooth, precise torque even at ultra-low speeds.

• Geroler® Roller Geometry: Incorporates roller contacts in the star-and-ring set to minimize startup friction, providing pulse-free operation in LSHT conditions.

• Superior Load Resilience: Equipped with heavy-duty tapered roller bearings, the shaft handles immense radial and axial loads directly—simplifying machine design by removing the need for external bearing supports.

• Genuine Drop-in Compatibility: Fully compliant with SAE mounting standards, ensuring 100% compatibility with original Eaton Char-Lynn systems for seamless maintenance and performance upgrades.

• Technical Spec Decoding:

  • 104-102x: Identifies the 2000 Series frame with specific flanges (e.g., 2-Bolt SAE A) and shaft configurations.

  • Suffix -006: Denotes the standard industrial configuration sequence.

Detailed Models & Specifications:

• Core Series: Eaton Char-Lynn 2000 Series (Disc Valve Motor).

• Featured Model Matrix:

  • 104-1023-006 / 104-1024-006: Core displacement frames for standard industrial drive tasks.

  • 104-1025-006 / 104-1026-006: High-torque frames optimized for heavy lifting or extrusion cycles.

  • 104-1027-006: High-output variant within the 2000 series spectrum.

• Core Performance Specs:

  • Rated Pressure: Continuous up to 200 Bar (3000 PSI); intermittent peaks up to 310 Bar.

  • Torque Capability: Peak torque outputs ranging from 450 Nm to over 900 Nm (displacement dependent).

  • Mounting Standards: Fully compliant with SAE 2-Bolt / 4-Bolt specifications.
