Duplomatic Type DS5 Valve | DS5-S1 DS5-S4 DS5-TA | NG10 Solenoid Valve | 24V DC
| Model Number | DS5-TA/14N-D24/K1 |
|---|
Product Description
Duplomatic Type DS5 Series High-Performance Solenoid Directional Valves
Product Overview: The DS5 Series is a direct-operated solenoid directional control valve complying with ISO 4401-05 (CETOP 05) standards. Featuring a universal Size 10 (NG10) footprint, these valves are specifically engineered for industrial hydraulic systems requiring high flow capacities and high operating pressures. Known for their rugged cast-iron bodies and optimized internal galleries, the DS5 series is the premier choice for heavy-duty machine tools, metallurgical equipment, large press controls, and automated production lines.
This category focuses on primary models from the 14N design sequence: including the 3-position closed center DS5-S1, the open center DS5-S4, and the 2-position DS5-TA.
Key Technical Advantages:
Heavy-Duty Wet-Pin Solenoids: Armatures operate fully immersed in oil for superior self-lubrication and cooling, ensuring smooth switching and low noise even during high-frequency cycles.
Low Pressure Drop Engineering: Precision-cast internal flow paths minimize fluid resistance, allowing for a high pressure rating of 315 Bar while maximizing energy efficiency through reduced pressure loss.
Standardized Electrical Interface: Equipped with D24 (24V DC) coils and K1 (Standard DIN connector) interfaces, ensuring rapid electrical integration and simplified field maintenance.
Global Interchangeability: Mounting patterns comply with international standards, allowing for direct replacement of leading brands like Rexroth, Vickers, or Parker of the same size.
Detailed Specifications & Parameters:
Core Series: Duplomatic Type DS5 Solenoid Valve.
Featured Model Matrix: DS5-S1/14N-D24/K1, DS5-S4/14N-D24/K1, DS5-TA/14N-D24/K1.
Core Performance Specs:
Nominal Size: Size 10 (NG10 / CETOP 05).
Max Operating Pressure: Rated up to 315 Bar (4,500 PSI).
Max Flow Capacity: Up to 120 L/min (32 GPM).
Voltage Specs: D24 (24V DC Supply).
Spool Functions: S1 (Closed center), S4 (Open center), TA (2-position end-to-end).
Design Sequence: 14N Series.
