Denison Type T6ED Double Vane Pump | T6ED-050-045, T6ED-062-042, T6ED-072-050

Denison Type T6ED Series High-Pressure Industrial Double Vane Pumps

Product Overview: The T6ED Series double fixed displacement vane pump is the definitive power solution for heavy industrial and mobile machinery. Integrating the T6E (high-flow end) and T6D (medium-flow end) cartridges on a single drive shaft, this series provides independent dual-circuit supply—perfect for complex systems requiring flow splitting or high-flow combination. Featured specifications include: T6ED-050-045-1R00-B1, T6ED-062-042-1L00-B1-J224, T6ED-072-050-1R12-C1, and T6ED-072-050-1R05-B1. Powered by patented Double-lip Vane technology, the T6ED series maintains maximum volumetric efficiency and ultra-quiet performance even at pressures up to 24.0 MPa (3500 PSI).

Key Technical Advantages:

• Double-lip Vane Durability: The patented design minimizes contact stress on the stator cam ring, ensuring superior fatigue resistance and long life under high-pressure cycles.

• Rapid Cartridge Replacement: Both E and D-end cartridges are independent “drop-in” modules. Maintenance crews can swap the internal core on-site to restore factory performance without disconnecting plumbing.

• Low Noise & Vibration: Optimized internal flow channels significantly suppress pulsations, maintaining decibel levels far lower than gear pumps of comparable power—ideal for indoor environments.

• High Contamination Tolerance: Built with rugged cast iron housings and hardened precision components to withstand micro-particles common in industrial and mobile hydraulic fluids.

• Target Applications: Large injection molding machines, brick presses, scrap metal shears, off-highway trucks, and marine winches.

Detailed Models & Parameters:

• Core Series: Denison Type T6ED Series (Double Vane Pump).

• Model Keywords: T6ED-050-045, T6ED-062-042, T6ED-072-050, T6ED062038, T6ED-072-050.

• Displacement Ratings (cm³/rev):

  • Shaft End (P1 – E Series): 158.0 (050), 190.0 (062), 213.0 (072).

  • Cover End (P2 – D Series): 120.0 (038), 132.0 (042), 142.0 (045), 158.0 (050).

• Technical Specs Decoding:

  • 1R / 1L: Rotation direction (R-Clockwise, L-Counter-Clockwise).

  • 00 / 05 / 12: Drive shaft configuration (Keyed, splined, or reinforced).

  • B1 / C1: Porting flange standard and orientation.

  • J224: Specific design sequence or seal configuration.

• Max Operating Pressure: Rated continuous pressure up to 24.0 MPa (240 Bar / 3500 PSI).
