Danfoss Solenoid Coil 042N0840 | AM230C | 230V 50/60Hz | 10mm Inner Hole | 32mm Height | Replacement Coil

Danfoss 042N0840 AM230C Solenoid Coil (10mm Hole)

Product Overview: The Danfoss 042N0840 is a highly versatile solenoid coil extensively used in industrial automation and refrigeration systems. As a key model within the AM230C series, it is engineered for 230V AC power supplies, offering exceptional electromagnetic conversion efficiency and heat dissipation. Its primary physical hallmarks—a 10mm inner hole and 32mm height—ensure a precise fit for a wide array of direct-operated and pilot-operated valve bodies. Encapsulated in high-grade insulating material, this coil maintains peak reliability even under continuous duty and high-frequency cycles.

Key Technical Advantages:

• Precise Mechanical Fit: Strict tolerance control of the 10mm inner diameter ensures a snug fit on the armature tube, reducing magnetic flux leakage.

• Dual-Frequency Efficiency: Compatible with both 50Hz and 60Hz industrial grids, providing consistent holding force at a 7.5W power rating.

• Heavy-Duty Encapsulation: Epoxy resin-molded construction resists moisture, dust, and industrial vibrations, significantly extending electrical service life.

• Snap-On Installation: Standardized design allows for tool-free, rapid replacement on-site, minimizing system downtime.

Detailed Specifications & Parameters:

• Part Number: 042N0840

• Series: AM230C

• Rated Voltage: 230V AC (50/60Hz)

• Power Consumption: 7.5W

• Physical Dimensions:

  • Inner Hole Diameter: 10 mm

  • Overall Height: 32 mm

• Insulation Class: Class H or higher

• Electrical Interface: Standard DIN 43650-A (3-spade connector)
