Danfoss OMS Series Motor | OMS375 OMS200 OMS125 | 151F0509 151F3004 151F2379

Danfoss OMS Series High-Performance Cycloid Orbit Motors

Product Overview: The Danfoss OMS Series is synonymous with high performance and durability in the global hydraulic drive industry. Utilizing advanced Disc Valve technology, these cycloid motors are specifically engineered to maintain consistent high-torque output under demanding high-pressure conditions. This category focuses on key models and precise part numbers: OMS375 (151F0509), OMS200 (151F3004), OMS125 (151F2379), and general specification 151F2334.

By integrating a high-performance Geroler gear set, the OMS series significantly reduces internal friction and elevates startup efficiency. Its rugged construction and superior bearing capacity make it the premier choice for agricultural propel drives, material handling cranes, forestry harvesters, heavy-duty conveyors, and injection molding machinery.

Key Technical Advantages:

• Disc Valve Technology: An independent valve plate automatically compensates for wear under pressure, ensuring maximum volumetric efficiency throughout the motor’s lifespan.

• Superior Bearing Resilience: Equipped with oversized tapered roller bearings, the output shaft directly handles substantial radial and axial loads.

• Elite Smoothness: Delivers pulse-free power even at ultra-low speeds, ensuring precision in complex mechanical operations.

• 100% OEM Interchangeability:

  • 151F0509 (OMS375): Optimized for high-displacement, high-torque requirements.

  • 151F3004 (OMS200): The benchmark choice for medium-duty drive systems.

  • 151F2379 / 151F2334: Industrial standard part numbers for guaranteed fit-and-function replacement.

Detailed Specifications & Parameters:

• Core Series: Danfoss OMS Series (Disc Valve Motor).

• Featured Model Matrix: OMS375, OMS200, OMS125, 151F0509, 151F3004, 151F2379, 151F2334.

• Core Performance Specs:

  • Displacement Range: 80 cc/rev to 375 cc/rev.

  • Rated Pressure: Continuous up to 210 Bar (3050 PSI); Intermittent peaks reaching 280 Bar (4050 PSI).

  • Torque Capability: Continuous torque up to 820 Nm, with intermittent peaks up to 1000 Nm.

  • Flow Capacity: Supports continuous flow inputs of up to 75 L/min.

  • Mounting Standards: SAE A 2-Bolt (Ø82.5mm) or 4-Bolt square flanges; Shaft options include 32mm Keyed, Splined, or Tapered designs.
