Danfoss MBC 5100 Pressure Switch | 061B100566 | 061B105266 | 061B000666 | 0.2-4 Bar
| Model Number | MBC5100 061B000666 12113DB04 0.2-4BA |
|---|
Product Description
Danfoss MBC 5100 Block-type Pressure Controllers
Product Overview: The MBC 5100 Series is a block-type pressure controller engineered specifically for demanding industrial and marine applications. Featuring a compact, modular architecture, the MBC 5100 offers superior resistance to intense vibrations and shock. As a key member of Danfoss’s marine-certified family, it is widely utilized in engines, pump sets, compressors, and hydraulic systems for precise pressure monitoring and alarm signaling. Its specialized piston or bellows design ensures long-term switching accuracy even in the harsh environments of engine rooms.
Featured part numbers include: 061B100566, 061B105266, 061B000666, and configuration codes 3641-1DB04 and 12113DB04.
Key Technical Advantages:
Global Marine Certifications: Compliant with all major classification societies (DNV, GL, LR, BV, etc.), making it ideal for engine and pump rooms.
High Vibration Resistance: The block design minimizes false triggering caused by mechanical vibrations, significantly extending contact life.
Low Hysteresis: Delivers precise control feedback, ensuring systems operate efficiently within the set pressure differential.
Sensitive Pressure Ranges: Especially optimized for 0.2-4 Bar low-pressure monitoring with exceptional sensitivity.
Detailed Specifications & Parameters:
Core Part Number Matrix:
MBC 5100-061B100566: Standard block-type pressure controller.
061B105266 / 061B000666: Marine-grade specifications optimized for specific setpoints or differentials.
3641-1DB04 / 12113DB04: Corresponding electrical interface and connection codes.
Core Technical Specs:
Pressure Range: 0.2 – 4 Bar (dedicated for low-pressure monitoring).
Max Working Pressure (MWP): Up to 150 Bar or higher depending on the specific model.
Electrical Connection: Standard DIN 43650 plug.
Enclosure Rating: IP65.
Contact Type: Single Pole Double Throw (SPDT) microswitch.
