Danfoss OMR OMT OMV Series Motor | OMR050C OMR100C OMR160C | OMV800

Danfoss O-Series Hydraulic Motors – OMR C, OMT & OMV Solutions

Product Overview: Danfoss orbital hydraulic motors are the global benchmark for power and reliability in industrial and mobile machinery. This category provides comprehensive access to the full O-Series lineup, featuring the compact OMR C Series (including OMR050C, OMR100C, OMR160C) and the heavy-duty OMV Series (ranging from OMV315 to OMV800).

The OMR C Series utilizes optimized spool valve technology, maintaining a compact footprint while significantly enhancing radial load capacity—perfect for agricultural machinery, conveyors, and light industrial drives. Conversely, the OMV Series serves as the heavy-duty “Titan” of the family, utilizing a disc valve design engineered for extreme pressures and massive torque demands in applications like heavy-duty winches and boring drives.

Key Technical Advantages:

• High-Performance Geroler Set: Advanced gear set geometry minimizes friction, ensuring consistent, pulse-free torque delivery throughout the motor’s lifespan.

• OMR C Compact Excellence: The C-Series balances lightweight construction with structural reinforcement for space-constrained environments, offering elite power density.

• OMV Heavy-Duty Bearings: OMV motors are equipped with oversized tapered roller bearings to handle substantial axial and radial shaft loads directly.

• Resilient High-Pressure Sealing: Standard high-pressure seals manage back-pressure spikes efficiently, extending service intervals and protecting internal components.

Detailed Specifications & Parameters:

• Core Series: Danfoss OMR, OMT, OMV, OMS, OMH, OML.

• Featured Model Matrix: OMR050C, OMR100C, OMR160C, OMV315, OMV400, OMV500, OMV630, OMV800.

• Core Performance Specs:

  • Displacement Range: 8 cc/rev (OML) to 800 cc/rev (OMV).

  • Rated Pressure: Continuous up to 210 Bar; Intermittent peaks exceeding 280 Bar.

  • Torque Capability: Spanning from 90 Nm (OMR050C) to over 2100 Nm (OMV800).

  • Speed Capacity: OMR C series supports speeds up to 750-1000 RPM (displacement dependent).

  • Mounting Standards: SAE A 2-Bolt, 4-Bolt Square, and Wheel Mount flanges with Keyed, Splined, or Tapered shaft options.

151B-3104 OMV 800 HYDRAULIC MOTOR
151B-3105 OMV 315 HYDRAULIC MOTOR
151B-3106 OMV 400 HYDRAULIC MOTOR
151B-3107 OMV 500 HYDRAULIC MOTOR
151B-3108 OMV 630 HYDRAULIC MOTOR
151B-3109 OMV 800 HYDRAULIC MOTOR
151B-3110 OMV 315 HYDRAYLIC MOTOR
151B-3111 OMV 400 HYDRAULIC MOTOR
151B-3113 OMV 630 HYDRAULIC MOTOR
151B-3114 OMV 800 HYDRAULIC MOTOR
151B-3132 OMV 500 HYDRAULIC MOTOR
151B-3136 OMV 500 HYDRAULIC MOTOR
151B-3173 OMV 630 HYDRAULIC MOTOR
151B-3178 OMV 630 HYDRAULIC MOTOR
151B-3179 OMV 800 HYDRAULIC MOTOR
151B-3180 OMV 400 HYDRAULIK MOTOR
151B-3183 OMV 800 ?50 CYL.
151B-3189 OMV 630 50CYL HYDRAULIC MOTOR
151B-3192 OMV 400 HYDRAULIC MOTOR
151B-3200 OMT 160 FX HYDRAULIC MOTOR
151B-3205 OMT 500 FX HYDRAULIC MOTOR
