CBF Series Forklift Gear Pump | CBF-F410, F412, F425, E440 | High Pressure Hydraulic Oil Pump

CBF Series High-Pressure Hydraulic Gear Pumps for Forklifts

Product Overview: The CBF Series stands as the premier hydraulic power core engineered specifically for internal combustion and electric forklifts. This comprehensive range features displacements from 10cc (CBF-F410) to 40cc (CBF-E440). Serving as the primary pump for lifting, tilting, and steering systems, the CBF series utilizes high-strength cast-iron bodies and advanced pressure-balance compensation technology. These pumps ensure elite volumetric efficiency and an extended service life under heavy lifting cycles, making them the top choice for OEM and aftermarket maintenance for brands like HELI, Hangcha, and Lonking.

Key Technical Advantages:

• Heavy-Duty Industrial Build: Constructed with high-strength cast-iron bodies for exceptional fatigue resistance, built to withstand the frequent pressure spikes and extreme loads of forklift operations.

• Superior Volumetric Efficiency: Features floating bushings and automatic side-plate compensation to minimize internal leakage, maintaining efficiencies above 92% at rated pressure for faster lifting speeds.

• Quiet-Running Technology: Precision-ground gear sets combined with optimized relief grooves drastically reduce hydraulic ripples and operational noise, meeting environmental standards for indoor warehousing.

• Robust Contamination Resistance: Specialized bearing architectures and sealing materials ensure reliable performance in harsh, dusty, or high-humidity job sites.

• Seamless Interchangeability: Available with standard splined shafts, keyed shafts, and multiple flange configurations (rectangular/diamond) for “Plug-and-Play” replacement with original equipment.

Detailed Models & Parameters:

• Core Series: CBF Forklift Hydraulic Series.

• Model Keywords: CBF-F410, CBF-F412, CBF-F414, CBF-F416, CBF-F418, CBF-F420, CBF-F425, CBF-F432, CBF-E440.

• Displacement Range: 10 cm³/rev to 40 cm³/rev.

• Pressure Ratings: Rated at 200 – 250 Bar (2900 – 3625 PSI) continuous.

• Rotation: Available in Counter-clockwise (L) or Clockwise (R).

• Target Applications: 1-10 ton forklift lift pumps, hydraulic pallet jacks, stacker steering systems, and compact loaders.
