Atos Type DLHZO Series High-Performance Digital Proportional Servo Valves

Product Overview: The DLHZO Series represents the pinnacle of Atos electro-hydraulic proportional valves, featuring a high-response design available in Size 06 (NG6). What sets this series apart is the specialized “Spool-in-sleeve” construction, which eliminates casting irregularities to provide exceptional linearity and dynamic response. Equipped with Integrated Digital Amplifiers (TES or LEB), DLHZO valves enable high-precision closed-loop control of position, velocity, and force, making them the premier choice for high-end industrial machinery, plastics processing, and aerospace simulators.

Featured prominently are the standard digital control model DLHZO-TES-SN-NP-040-L73 and the enhanced performance specification DLHZO-LEBQP-SN-NP-060V71.

Key Technical Advantages:

• Servo-Level Precision: The precision-ground spool and sleeve assembly delivers ultra-low hysteresis (< 0.1%) and superior repeatability, rivaling traditional servo valve performance.

• Integrated Digital Amplifiers (OBE): The TES/LEB versions feature on-board digital controllers allowing for software-based parameter tuning, diagnostics, and fieldbus options (CANopen, EtherCAT).

• High Dynamic Frequency Response: Optimized electromagnetic drives ensure stable gain and phase even under high-frequency step signals, meeting the demands of rapid switching cycles.

• Closed-Loop Position Feedback: An integrated LVDT sensor monitors spool position in real-time, with corrections handled by the on-board electronics to ensure flow output remains independent of load pressure fluctuations.

Detailed Specifications & Parameters:

• Core Series: Atos Type DLHZO High Performance Series.

• Featured Model Matrix:

  • DLHZO-TES-SN-NP-040-L73 (TES Digital, 040 Flow Rating, L73 Spool Function)

  • DLHZO-LEBQP-SN-NP-060V71 (LEB Advanced Digital, 060 Flow Rating, V71 Special Spool)

• Core Performance Specs:

  • Nominal Size: Size 06 (NG6 / CETOP 03).

  • Max Operating Pressure: Rated up to 315 Bar – 350 Bar (4,500 PSI).

  • Nominal Flow Rate: Covers 40 L/min to 60 L/min depending on model (at standard pressure drops).

  • Control Signal: SN-NP (Analog input ±10V or 4-20mA, without fieldbus).

  • Protection Class: IP67 for integrated electronics, with high vibration resistance.
