4WE6 Solenoid Valve | 4WE6D61 | 4WE6H61 | 4WE6C61 | 12V 24V DC 110V AC | NG6 CETOP 3 Hydraulic Valve

Model Number

4WE, 4WE6, 4WE6E, 4WE6C, 4WE6D, 4WE10, 4WE6H61/CW110-50N9K4, 4WE6D61/OCG24N9K4, 4WE6C61/CG12N9K4

Inquiry

Product Description

4WE6-61 Series High-Performance Solenoid Directional Valves

Product Overview: The 4WE6 series is a range of high-performance, direct-operated solenoid directional control valves, fully compliant with ISO 4401-03 (NG6 / CETOP 3) mounting standards. As a benchmark in industrial hydraulics, the 61 design series is renowned for its optimized flow paths, low pressure-drop characteristics, and high switching frequency. Utilizing wet-pin solenoid technology, the armature operates within the hydraulic fluid, ensuring near-silent switching and superior heat dissipation for 100% ED (Continuous Duty) cycles.

Featured models include: 4WE6H61/CW110-50N9K4, 4WE6D61/OCG24N9K4, and 4WE6C61/CG12N9K4.

Key Technical Advantages:

  • Proven 61 Series Design: The optimized valve body casting reduces flow resistance, maintaining stable system temperatures even under high-pressure and high-flow conditions.

  • Full Voltage Adaptability: Available in CG12 (12V DC), G24 (24V DC), and CW110 (110V AC) coils, catering to diverse global electrical standards.

  • Versatile Control Logic: Supports core spool functions such as D (2-pos 4-way), H (3-pos 4-way, open center), and C (2-pos 4-way with spring return) to meet complex hydraulic sequence requirements.

  • Industrial Durability: Equipped with K4 (DIN 43650) standard connectors and featuring an N9 manual override button for safe operation during commissioning or power failure.

Detailed Specifications & Parameters:

  • Featured Model Matrix:

    • 4WE6H61/CW110-50N9K4: Size 6, H-spool (open center), 110V AC control, 61 design series.

    • 4WE6D61/OCG24N9K4: Size 6, D-spool (2-pos 4-way), 24V DC control, equipped with high-performance OCG coils.

    • 4WE6C61/CG12N9K4: Size 6, C-spool (2-pos 4-way with return), 12V DC control, ideal for mobile or compact systems.

  • Core Technical Specs:

    • Mounting Standard: NG6 / CETOP 3 / ISO 4401-03.

    • Max Operating Pressure: Rated at 31.5 MPa (315 bar).

    • Max Flow Capacity: Up to 60 – 80 L/min (depending on spool type).

    • Electrical Connection: Standard DIN 43650 interface.
