Rexroth Type 4WE10 Solenoid Valve | 4WE10E | 4WE10J | 4WE10G | 4WE10D | 24V DC 220V AC | NG10 CETOP 5

Model Number

4WE10E3X/CG24N9K4

Inquiry

Product Description

4WE10 Series High-Flow Direct-Operated Solenoid Valves

Product Overview: The 4WE10 series is a premium range of direct-operated solenoid spool valves designed for the Size 10 (NG10 / CETOP 5) mounting standard. Compared to the Size 6 series, the 4WE10 offers significantly higher flow capacity (up to 160 L/min), effectively reducing system pressure drop and increasing actuator speed. Utilizing wet-pin solenoid technology, these valves feature superior heat dissipation and eliminate the risk of oil leakage at dynamic seals. From high-frequency industrial production lines to demanding heavy-duty machinery, the 4WE10 ensures long-term, stable directional switching.

Featured models include: 4WE10E31/CW220-50N9Z5L, 4WE10J31B/CG24N9Z4, 4WE10G33/CW230RN9Z5L, and 4WE10D3X/CW110N9K4.

Key Technical Advantages:

  • High Flow & Low Pressure Drop: Optimized internal gallery design ensures minimal energy loss even under peak flow conditions.

  • Global Power Compatibility: Supports CG24 (24V DC), CW220/230 (220V/230V AC), and CW110 (110V AC), with electrical interfaces including Z5L, Z4, and K4 connectors.

  • Precision Spool Logic: Available in E (Closed center), J (Unloading center), G (H-spool), and D (2-pos) configurations to match diverse circuit requirements.

  • Durability & Safety: Equipped with the N9 manual override button for emergency spool actuation during power outages; robust sealing supports continuous duty (100% ED).

Detailed Specifications & Parameters:

  • Featured Model Matrix:

    • 4WE10E31/CW220-50N9Z5L: Size 10, E-spool, 31 series, 220V AC power, with Z5L junction box.

    • 4WE10J31B/CG24N9Z4: Size 10, J-spool, 31B series, 24V DC control, with Z4 connector.

    • 4WE10G33/CW230RN9Z5L: Size 10, G-spool, 33 series, 230V AC, reinforced heat-resistant coil.

    • 4WE10D3X/CW110N9K4: Size 10, D-spool (2-pos), 3X design series, 110V AC actuation.

  • Core Technical Specs:

    • Mounting Interface: ISO 4401-05 / CETOP 5 / NG10.

    • Max Operating Pressure: Rated up to 31.5 MPa (315 bar).

    • Flow Capacity: Up to 120 – 160 L/min.

    • Protection Class: IP65 rating with appropriate connectors.

Company Profile

We adhere to international quality management standards and provide a 1-year warranty including maintenance and replacement. We have established long-term strategic cooperation with many well-known brands and continuously launch new products to meet market development. Flexible payment terms are supported, including USD settlement, Alipay, Western Union and T/T.

Relying on our standardized production base and professional foreign trade team, we provide competitive factory direct prices, efficient logistics channels and punctual delivery. FJZY Hydraulic is devoted to being your trustworthy long-term partner in hydraulic and agricultural machinery fields.
